Qaybta
K3X6X7
Cirbadaha cirbadaha ayaa isticmaala rollers cylindrical leh dhererka ilaa dhexroorka oo ka badan 4:1. Joomatari “ irbad u eg” ayaa awood u siineysa awooda culeyska shucaaca ee gaarka ah gudaha qeybaha aadka isku dhafan, taasoo bixisa hufnaan meel sare leh marka loo eego xajmiyada kubbadda ee cabbirada u dhigma.
Cirbadaha Roller Biarings
| ISO | K3X6X7 | |
| Dhexroorka jidka Raceway giraanta gudaha | Fw | 3 mm |
| Dhexroor ka baxsan | Ee | 6 mm |
| Ballaca | Bc | 7 mm |
| Qiimaynta culeyska firfircoon ee aasaasiga ah | C | 0.69 kN |
| Qiimaynta culeyska aasaasiga ah ee taagan | C0 | 0.47 kN |
| Xawaaraha xaddidaya | 22600 r/daqiiqo | |
| Qaadista tirada badan | 0.0004 kg | |
Burburka qaabdhismeedka
Qaybaha muhiimka ah waxaa ka mid ah:
- Giraanta dibadda: Caadi ahaan leh jidka orodka (noocyada qafis la'aanta ah waxay ka tagaan giraanta dibadda)
- Rollers irbadoRollers-godka saxda ah ee ku gudbinaya culeyska iyada oo loo marayo xiriirka khadka
- Qafis: Naxaasta/birta/polymer-ka alaabada kala dheereeya rollers (noocyada qafis la'aanta ah waxay ka reebayaan qafis)
- Giraanta Gudaha: Qayb ikhtiyaari ah (tusaale, NA-nooca leh giraanta gudaha, nooca RNA oo aan lahayn)
Nidaamka Kala-saarista
- Naqshadeynta: Dhameystir buuxa (load sare), qafis (xawaaraha sare oo karti leh)
- Shaqaale ahaan: shucaac, riixid, xajisyo isku dhafan
- Noocyada Gaarka ah: Flanged (meelaynta axial), toosinta ( magdhowga khaldan)
Faa'iidooyinka Farsamada
| Muuqaal | Faa'iidada injineernimada |
| Qaybta caatada ah | Waxay badbaadisaa 60% meel radial ah |
| Cufnaanta culeyska sare | 300% awoodda sare vs. kubadaha |
| Iska caabin naxdin leh | Xidhiidhka khadka ayaa qaybiya walbahaarka |
| Saxnaanta wareegga | ± 0.03mm nidaamyada saxda ah |
| Fiiro gaar ah: Xadaynta xawaaruhu waxay ku kala duwan tahay walxaha qafiska |
Codsiyada Warshadaha
- BaabuurGudbinta (tusaale, JTEKT NK17/20), isku xidhka ulaha
- RoboticsKala-goysyada go'an (nooc dhammaystir ah oo buuxa ayaa baahsan)
- Hawada hawada: APU rotor xadhkaha taageerada
- Caafimaad: CT scanner gantry rotation (noocyada badbaadada MRI)
- DhismahaBambooyinka Haydarooliga ah (Timken TOR 47)
La qabsiga Deegaanka
| Xaalad | Xalka lagu taliyay |
| Heerkulka sare | Rollers-dahaarka dhoobada + baqashada gaarka ah |
| Warbaahin daallan | Bir aan bir lahayn oo buuxda (SSffix) |
| Meelaha wasakhaysan | Xirmooyinka xiriirka laba-dibnood (2RS) |
| Xawaaraha aadka u sarreeya | Qafisyada polimer + saliid-hawada saliidda |
